LILYGO® TTGO T-Journal ESP32 Camera Module Development Board OV2640 Camera SMA Wifi 3dbi Antenna 0.91 OLED Camera Board

上市日期: 2019-06-04
建议销售价: 0

LILYGO® TTGO T-Journal ESP32 Camera Module Development Board OV2640 Camera SMA Wifi 3dbi Antenna 0.91 OLED Camera Board

LILYGO® TTGO T-Journal ESP32 Camera Module Development Board OV2640 Camera SMA Wifi 3dbi Antenna 0.91 OLED Camera Board

Product Description

Hardware

Chipset ESPRESSIF-ESP32-PCIO-D4 240MHz Xtensa® single-/dual-core 32-bit LX6 microprocessor
FLASH QSPI flash/SRAM, up to 4 x 16 MB
SRAM 520 kB SRAM
KEY reset,IO32
dispaly 0.91 SSD1306
Power indicator lamp red
USB to TTL CP2104
Camera OV2640  2Megapixel
Steering engine analog servo
on-board clock 40MHz crystal oscillator
working voltage 2.3V-3.6V
working current about 160mA
working temperature range -40℃ ~ +85℃
size 64.57mm*23.98mm
Power Supply Specifications
Power Supply USB 5V/1A
charging current 1A
battery 3.7V lithium battery


WIFI

Standard FCC/CE/TELEC/KCC/SRRC/NCC(esp32 chip)
protocol 802.11 b/g/n/e/i (802.11n,speed up to150Mbps)A-MPDU and A-MSDU polymerization,support 0.4μS Protection interval
frequency range 2.4GHz~2.5GHz(2400M~2483.5M)
Transmit Power 22dBm
communication distance 300m


Bluetooth
protocol meet bluetooth v4.2BR/EDR and BLE standard
radio frequency with -98dBm sensitivity NZIF receiver Class-1,Class-2&Class-3 emitter AFH
audio frequency CVSD&SBC audio frequency


Software Specification

wifi Mode Station/SoftAP/SoftAP+Station/P2P
security mechanism WPA/WPA2/WPA2-Enterprise/WPS
Encryption Type AES/RSA/ECC/SHA
firmware upgrade UART download/OTA(Through network/host to download and write firmware)
Software Development Support cloud server development /SDK for user firmware development
networking protocol IPv4、IPv6、SSL、TCP/UDP/HTTP/FTP/MQTT
User Configuration AT + Instruction set, cloud server, android/iOSapp
OS FreeRTOS



Product Size

LILYGO® TTGO T-Journal ESP32 Camera Module Development Board OV2640 Camera SMA Wifi 3dbi Antenna 0.91 OLED Camera Board



Product Details



LILYGO® TTGO T-Journal ESP32 Camera Module Development Board OV2640 Camera SMA Wifi 3dbi Antenna 0.91 OLED Camera Board

LILYGO® TTGO T-Journal ESP32 Camera Module Development Board OV2640 Camera SMA Wifi 3dbi Antenna 0.91 OLED Camera Board



Pin Diagram

LILYGO® TTGO T-Journal ESP32 Camera Module Development Board OV2640 Camera SMA Wifi 3dbi Antenna 0.91 OLED Camera Board

You can use the camera library for arduino:
https://github.com/LilyGO/ESP32-Camera


The difference between Fish-eye lens and normal

LILYGO® TTGO T-Journal ESP32 Camera Module Development Board OV2640 Camera SMA Wifi 3dbi Antenna 0.91 OLED Camera BoardLILYGO® TTGO T-Journal ESP32 Camera Module Development Board OV2640 Camera SMA Wifi 3dbi Antenna 0.91 OLED Camera Board








Connect Camera

Using Nano carbon aluminum foil heat sink

LILYGO® TTGO T-Journal ESP32 Camera Module Development Board OV2640 Camera SMA Wifi 3dbi Antenna 0.91 OLED Camera Board



Shipping List

1 X ESP32 Camera Module(Normal Lens Or Fish-eye Lens)

1 X Wi-Fi Antenna

1 X Power Line



LILYGO® TTGO T-Journal ESP32 Camera Module Development Board OV2640 Camera SMA Wifi 3dbi Antenna 0.91 OLED Camera Board

LILYGO® TTGO T-Journal ESP32 Camera Module Development Board OV2640 Camera SMA Wifi 3dbi Antenna 0.91 OLED Camera Board

LILYGO® TTGO T-Journal ESP32 Camera Module Development Board OV2640 Camera SMA Wifi 3dbi Antenna 0.91 OLED Camera Board

LILYGO® TTGO T-Journal ESP32 Camera Module Development Board OV2640 Camera SMA Wifi 3dbi Antenna 0.91 OLED Camera Board



LILYGO® TTGO T-Journal ESP32 Camera Module Development Board OV2640 Camera SMA Wifi 3dbi Antenna 0.91 OLED Camera Board
