LILYGO® BME280 Moudle Temperature Humidity Air pressure Trinity Environmental Sensor

上市日期: 2019-08-20
建议销售价: 0

BME280 Moudle Temperature Humidity Air Pressure, Trinity Environmental Sensor

LILYGO® BME280 Moudle Temperature Humidity Air pressure Trinity Environmental Sensor



Product Description



Working voltage: 3.3~5V
Working current: 2mA
Working temperature: -40 ° C ~ +85 ° C
Temperature detection range: -40 ° C ~ +85 ° C, resolution 0.1 ° C, error ± 0.5 ° C
Humidity detection range: 0~100%RH, resolution 0.1%RH, error ±2%RH
Pressure detection range: 300~1100hPa
Humidity measurement response time: 1s
Module size: 22 * 25 mm
Mounting hole size: inner diameter 3.1mm / outer diameter 6mm
Weight: 12g




Product Detail
LILYGO® BME280 Moudle Temperature Humidity Air pressure Trinity Environmental SensorLILYGO® BME280 Moudle Temperature Humidity Air pressure Trinity Environmental Sensor
It Can be used with T-Camera

LILYGO® BME280 Moudle Temperature Humidity Air pressure Trinity Environmental Sensor
LILYGO® BME280 Moudle Temperature Humidity Air pressure Trinity Environmental Sensor



Shipping List
1 X BME280 Moudle
1 x  Data line
LILYGO® BME280 Moudle Temperature Humidity Air pressure Trinity Environmental Sensor




LILYGO® BME280 Moudle Temperature Humidity Air pressure Trinity Environmental Sensor
