      Overview

This is an E-paper display module, 1.54inch, 200x200 resolution, with embedded controller, communicating via SPI interface, supports yellow, black, and white three-color display.

Due to the advantages like ultra low power consumption, wide viewing angle, clear display without electricity, it is an ideal choice for applications such as shelf label, industrial instrument, and so on.



Features

· No backlight, keeps displaying last content for a long time even when power down

· Ultra low power consumption, basically power is only required for refreshing

· Comes with development resources and manual (examples for Arduin-esp32)



Specifications

· Operating voltage: 3.3V

· Interface: 3-wire SPI, 4-wire SPI

· Display color: yellow, black, white

· Grey level: 2

· Refresh power: 26.4mW(typ.)

· Standby power: <0.017mW

· Viewing angle: >170°



Screen specifications

Part Number

Colors

Grey Level

Resolution

Display size (mm)

Outline Dimension (mm)

Full Refresh Time (s)

Partial Refresh Time (s)

Interface

1.54inch e-Paper

yellow, black, white

2

152x152

27.51 × 27.51

31.8 × 37.3

27

N/A

SPI

2.13inch e-Paper

yellow, black, white

2

212x104

48.55 × 23.71

59.2 × 29.2

15

N/A

SPI

2.9inch e-Paper

yellow, black, white

2

296x128

66.89 × 29.05

79.0 × 36.7

15

N/A

SPI

SYMBOL


VCC

3.3V

GND

Ground

DIN

SPI MOSI pin

CLK

SPI SCK pin

CS

SPI chip selection, low active

DC

Data/Command selection (high for data, low for command)

RST

External reset, low active

BUSY

Busy status output, low active



Product Diagram

LILYGO® TTGO T5S V2.4 Wifi Bluetooth Wireless Module Base ESP-32 Esp32 Yellow Display EPaper Sperker Electric Development Board

Product Size

LILYGO® TTGO T5S V2.4 Wifi Bluetooth Wireless Module Base ESP-32 Esp32 Yellow Display EPaper Sperker Electric Development Board

More Display

LILYGO® TTGO T5S V2.4 Wifi Bluetooth Wireless Module Base ESP-32 Esp32 Yellow Display EPaper Sperker Electric Development BoardLILYGO® TTGO T5S V2.4 Wifi Bluetooth Wireless Module Base ESP-32 Esp32 Yellow Display EPaper Sperker Electric Development Board






For more product information, please enter:

https://github.com/LilyGO/TTGO-T5-ePaper1.54

https://github.com/Xinyuan-LilyGO/LilyGo-T5-ink-series


Product Details



LILYGO® TTGO T5S V2.4 Wifi Bluetooth Wireless Module Base ESP-32 Esp32 Yellow Display EPaper Sperker Electric Development Board

LILYGO® TTGO T5S V2.4 Wifi Bluetooth Wireless Module Base ESP-32 Esp32 Yellow Display EPaper Sperker Electric Development Board

LILYGO® TTGO T5S V2.4 Wifi Bluetooth Wireless Module Base ESP-32 Esp32 Yellow Display EPaper Sperker Electric Development Board







Shipping List (Shipped according to the kind of your choice)

1 X T5 ESP-32 Module(Includes display screen and speakers)

1 X Power Cable

1 X Free Box
